DuPont SFP-2860 Ultrafiltration Membrane 8 Inch PVDF 51 m²

DuPont SFP-2860 Ultrafiltration Membrane 8 Inch PVDF 51 m²

DuPont SFP-2860 Ultrafiltration Membrane 8 Inch PVDF 51 m²
video
DuPont SFP-2860 Ultrafiltration Membrane 8 Inch PVDF 51 m²
Productdetails:
Place of Origin: China
Merknaam: DuPont
Certificering: CE
Model Number: SFP-2860
Betalen & Verzenden Algemene voorwaarden:
Minimum Order Quantity: 1 PC
Prijs: Onderhandelbaar
Packaging Details: standard export packing
Delivery Time: 5- 8 work days
Payment Terms: Western Union,T/T
Supply Ability: 60000 Units per Month
Contact
Alle producten
de doos van de verlichtingsdistributie (33)
elektrodistributiedoos (33)
Weerbestendige Distributiedoos (48)
De Doos van de glasvezelbijlage (60)
Automatische de Overdrachtschakelaar van ATS (68)
EDI-modules (139)
Ultrafiltratiemembraanmodules (62)
industriële stroomonderbreker (85)
zonnepv systeem (72)
Elektrische EV-het Laden Post (21)
Modulaire Timingsrelais (12)
De Relais van de automatiseringscontrole (64)
De Transformator van de voltageregelgever (16)
De Ballons van de filmverlichting (136)
Het Licht van de maanballon (131)
Driepoot LEIDENE Ballons (115)
Opblaasbare Lichte Toren (62)
Eindbloktoebehoren (6)
Gedetailleerde productomschrijving
Flow Range of SFP-2860: 2.0 – 6.1 m3 /hr Flow Range Membrane Area of SFP-2860: 51 m²
Nominal pore diameter of SFP-2860: 0.03 µm Material of SFP-2860: PVDF
Diameter of SFP-2860: 8 inch Flow direction settings: External pressure structure, dead end filtration
Component NaOCl (max.): 2,000 mg/L Component Max backwash pressure: 2.5 bar
Component Main Usage: Water Treatment Pretreatment Advantages: High filtration accuracy
Markeren:

DuPont SFP-2860 ultrafiltration membrane

,

8 inch PVDF ultrafiltration membrane

,

51 m² ultrafiltration membrane module

DuPont SFP-2860 Ultrafiltration Membrane RO Pretreatment 99.9% Bacteria Removal
Product Overview

The DuPont SFP-2860 is a high-performance PVDF hollow fiber ultrafiltration (UF) membrane designed for demanding water treatment applications. With a 50kDa molecular weight cutoff (MWCO) and 0.03 μm pore size, it effectively removes suspended solids, bacteria (>99.9%), and viruses (LRV≥4), making it ideal for municipal wastewater reuse, RO pretreatment, and industrial process water.

Key Specifications
Attribute Value
Flow Range 2.0 – 6.1 m³/hr
Membrane Area 51 m²
Nominal Pore Diameter 0.03 µm
Material PVDF
Diameter 8 inch
Flow Direction External pressure structure, dead end filtration
Max. NaOCl 2,000 mg/L
Max Backwash Pressure 2.5 bar
Key Features & Benefits
  • High Filtration Efficiency - 0.01-0.1 µm pore size for removal of turbidity, pathogens, and macromolecules
  • Low Fouling & High Flux - Hydrophilic PES material resists organic fouling, ensuring stable long-term performance
  • Chemical Resistance - Tolerates pH 1-13 (cleaning) and chlorine exposure
  • Compact & Modular Design - 8-inch standard housing for easy integration into existing UF/RO systems
  • Sustainable Operation - Low transmembrane pressure (TMP) reduces energy costs
Typical Applications
  • Pretreatment for RO/NF systems (seawater desalination, boiler feed water)
  • Drinking water purification (removal of bacteria, viruses, and turbidity)
  • Wastewater reuse (municipal/industrial wastewater tertiary treatment)
  • Food & Beverage processing (clarification, sterile filtration)
DuPont SFP-2860 Ultrafiltration Membrane 8 Inch PVDF 51 m² 0
Product Specifications
Model Type Part # Membrane Area (m²/ft²) Volume (Liters/Gallons) Weight (Kg/lbs)
SFP-2860 Pretreatment 280933 51 / 549 35 / 9.3 48/83 / 106/183
SFD-2860 NSF/ANSI 61 Drinking water 324168 51 / 549 35 / 9.3 48/83 / 106/183
Operating Parameters
Parameter SI Units US Units
Filtrate Flux @ 25ºC 40-120 l/m²/hr 24-70 gfd
Flow Range 2.0 - 6.1 m³/hr 9.2 - 26.7 gpm
Temperature 1-40ºC 34-104ºF
Max. Inlet Module Pressure (@ 20ºC) 6.25 bar 93.75 psi
Max. Operating TMP 2.1 bar 30 psi
Important Operation Information

Proper start-up of a UF system is essential for preparing the membranes for operational service and preventing membrane damage. Adhering to the correct start-up sequence ensures that operating parameters conform to design specifications, enabling attainment of system water quality and productivity targets.

Before commencing system start-up procedures, complete membrane pretreatment, installation of membrane modules, instrument calibration, and other system checks. Refer to the product technical manual for detailed instructions.

NOTICE: NSF/ANSI 61 certified drinking water modules require specific conditioning procedures before generating potable water. Please refer to the flushing section of the product technical manual for detailed procedures. Drinking water modules may be subject to additional regulatory constraints in certain countries.

DuPont SFP-2860 Ultrafiltration Membrane 8 Inch PVDF 51 m² 1
DuPont Ultrafiltration SFD 2860 XP IntegraFlux Module
DuPont SFP-2860 Ultrafiltration Membrane 8 Inch PVDF 51 m² 2
DuPont SFP 2860 XP IntegraFlux Ultrafiltration Module
